Procedure to program
Pre-Built sound
pack
(Boot loader Ver.1)
Step 1. Download compressed sound file, sound_pack_name.rar,
from website
Step 2.
Write email to distributor to get decompress password,
Step 3. Decompress
sound_pack_name_prog.bin
and
sound_pack_name_run_time.bin
from compressed sound file, password is needed at this step,
Step 4. Power
off TK board,
Step 5. Plug LED(
F003, LED
Main Gun Flasher)
to J3 as programming indicator,
Step 6. Load sound_pack_name_prog.bin to TK
programmer PC software, plug TK programmer to TK board
Step 7. Hit
Auto Start bottom to program TK
board if using TK Programmer PRO,
Hit write bottom to program TK
board if using TK Programmer, when
finish, disconnect TK programmer from TK board
Step 8. Power
on TK board,
programming indicator start flashing, wait till
flashing stops,
Step 9. Verify
sound effects, if anything wrong, contact us.
Step 10
Power off TK board,
Step 11.
Load
sound_pack_name_run_time.bin
to
to TK
programmer PC software, plug TK programmer to TK board
Step 7. Hit
Auto Start bottom to program TK
board if using TK Programmer PRO,
Hit write bottom to program TK
board if using TK Programmer,
Step 13.
Power on TK board, TK board runs with latest programmed sound, setting and
software
Procedure to program
Pre-Built sound
pack
(Boot loader Ver.2 and above)
Step
1. Download compressed sound file, sound_pack_name.rar,
from website
Step 2.
Write email to distributor to get decompress password,
Step 3.
Decompress
sound_pack_name_prog.bin
and
sound_pack_name_run_time.bin
from compressed sound file, password is needed at this step,
Step 4. Power
off TK board,
Step 5. Plug LED(
F003, LED
Main Gun Flasher)
to J3 as programming indicator,
Step 6.
Load
sound_pack_name_run_time.bin
to
to TK
programmer PC software, plug TK programmer to TK board.
Step 7. Hit
Auto Start bottom to program TK
board if using TK Programmer PRO,
Hit write bottom to program TK
board if using TK Programmer, when
finish, disconnect TK programmer from TK board
Step 8. Power
on TK board,
programming indicator start flashing, wait till
flashing stops,
Step 9. TK board runs with latest programmed sound, setting and
software
Reference video: https://www.youtube.com/watch?v=kS1e3jsTtBQ
Pre-built "E" variant sound packs for E variant board
Please contact regional distributor for files
Pre-built V2 sound packs for TK80/TK60/TK40/TK39/TK37/TK24 sound packs
Please watch our YouTube Channel
https://www.youtube.com/user/clarkmodel2003
for demonstration video
|
Sound Pack Code
|
Model
|
Release Schedule
/sound pack file |
|
38t_V1 |
Panzerkampfwagen 38(t)
Main armament: 3.7cm
Secondary armament: 7.92 mm ZB-53
Engine: Praga Typ TNHPS/II water-cooled, 6-cylinder
Gun elevation: Manual
Gun rotation: Manual |
Released
Download |
|
CEN |
UK
Centurion
Main armament:20 pdr
Secondary armament: .30 cal
Coaxial:
.30 cal
in
Coaxial sound mode
Commander's cupola machine gun:
30 cal
Engine: Rolls-Royce Meteor
Gun elevation: Motorized
Gun rotation: Motorized |
TBD |
|
CH2_V1
|
UK Challenger 2
Main armament:L30A1 120 mm rifled gun
Secondary armament:
Coaxial: 7.62 mm L94A1 chain gun EX-34
Commander's cupola machine gun:
7.62 mm L37A2
Engine: Perkins CV-12 V12
Gun elevation: Motorized
Gun rotation: Motorized
Licensed from Reality Studio Sound Team |
Released
Download |
|
Elefant |
German
Elefant Tank Destroyer
Main armament: 8.8 cm KwK
43 L/71
Secondary armament: Maschinengewehr 34 and 42
Engine: Twin Electric Motor, Twin Maybach HL 120 TRM
Gun elevation: Manual
Gun rotation: Motorized |
Released
Download |
|
JP_V1 |
German
JadgPanther
Main
armament:8.8 cm KwK
43 L/71
Secondary armament: Mg 34
Engine: Maybach HL 230 P30 with
flame muffler
Gun elevation: Manual
Turret rotation: Manual |
Released
Download |
|
JT_V1 |
German heavy tank destroyer
Jagdtiger
Main armament: 12.8 cm PaK 44
L/55
Secondary armament: Anti-aircraft MG-42
Engine: Maybach HL 230 P30,
Electric Start
Up
Gun elevation: Manual
Gun rotation: Manual
*Speaker with better low frequency response is recommended for 12.8cm cannon
sound |
Released
Download |
|
JT_V2 |
German heavy tank destroyer
Jagdtiger
Main armament: 12.8 cm PaK 44
L/55
Secondary armament: Anti-aircraft MG-42
Engine: Maybach HL 230 P30 Hand, Hand Crank Start Up
Gun elevation: Manual
Gun rotation: Manual
*Speaker with better low frequency response is recommended for 12.8cm cannon
sound |
Released
Download |
|
JS2 |
Russia
JS-2/JS-3
Main armament:
122mm
Secondary armament: DShK Heavy Machine Gun
Engine: Model V-2 V12 Diesel engine
Gun
elevation: Manual
Gun rotation:
Motorized |
Released
Download |
|
KT_V1 |
Based on
King Tiger in Saumur
Main armament: 8.8 cm KwK
43 L/71
Secondary armament: Maschinengewehr 34
Engine: Maybach HL 230 P30,
without Flammenvernichter
Muffle, Hand Crank Start Up
Gun elevation: Manual
Gun rotation: Motorized |
Released
Download |
|
KT_V2 |
Based on
King Tiger in Saumur by Stian Sollie
Main armament: 8.8 cm KwK
43 L/71
Secondary armament: Maschinengewehr 34
Engine: Maybach HL 230 P30,
without Flammenvernichter
Muffle,
Electric Start
Up
Gun elevation: Manual
Gun rotation: Motorized |
Released
Download |
|
L2 |
German
Leopard 2, ZTZ-99 and TYPE10
Main armament:Rheinmetal GmbH
120mm
Secondary armament: MG3A1
Engine: MB873
Gun elevation: Motorized
Turret rotation: Motorized |
Released
Download |
|
LUCHS |
PzKpfw.II Ausf. L Luchs
|
TBD |
|
M1
|
US
M1
Abrams
Main armament:120 mm L44 M256 smoothbore cannon
Secondary armament: M2HB heavy machine gun
Engine: Honeywell AGT1500C
Gun elevation: Motorized
Gun rotation: Motorized |
Released
Download |
|
M4_V1
|
US tank Version
Main armament:76mm
Secondary armament:
.30
Cal
Hull
Mount MG:.50 Cal
Commander's cupola machine gun:
Engine:
Continental R975-C4 Engine
Gun elevation: Manual
Gun rotation: Motorized |
Released
Download |
|
M4_V2 |
US tank Version
Main armament:76mm
Secondary armament:
.30
Cal
Hull
Mount MG:.50 Cal
Commander's cupola machine gun:
Engine:
Ford GAA V8 Tank Engine
Gun elevation: Manual
Gun rotation: Motorized |
Released
Download |
|
M41_V1 |
US
M41 Walker Bulldog/M113
Main armament:
Secondary armament:
Coaxial:
Commander's cupola
machine gun:
Engine: Continental
AOS 895-3 Engine
Gun elevation: Motorized
Gun rotation: Motorized |
Released
Download |
|
MAU |
Opel Mauliter
Main armament: 5 cm KwK 39 L/60
gun
Secondary armament:
MG34
Engine: Tatra
Gun elevation: Manual
Gun rotation: Motorized |
TBD |
|
PAN |
Based on
Saumur Panther by Stian Sollie
Main armament:7.5 cm KwK 40
Secondary armament: Mg 34
Engine: Maybach HL 230 P30 without
flame muffler
Gun elevation: Manual
Turret rotation: Motorized |
Released
Download |
|
PAN_V2 |
Based on
Trier Panther by Stian Sollie
Main armament:7.5 cm KwK 40
Secondary armament: Mg 34
Engine: Maybach HL 230 P30 with
flame muffler
Gun elevation: Manual
Turret rotation: Motorizedn |
Released
Download |
|
PAN_2017_V2 |
Based on
Trier Panther by Stian Sollie
Main armament:7.5 cm KwK 40
Secondary armament: Mg 34
Engine: Maybach HL 230 P30 with
flame muffler
Gun elevation: Manual
Turret rotation: Motorizedn |
Released
Download |
|
PZ4_V1 |
German
Panzer 4
Main armament:7.5
cm KwK 40
Secondary armament: Mg 34
Engine: 12-cylinder Maybach HL 120 TRM
Gun elevation: Manual
Turret rotation: Manual |
Released
Download |
|
PUMA |
German
Sd.Kfz. 234
Main armament: 5 cm KwK 39 L/60
gun
Secondary armament:
MG34
Engine: Tatra
Gun elevation: Manual
Gun rotation: Motorized |
TBD |
|
Stug_V1 |
German
Stug
Main armament:7.5
cm KwK 40
Secondary armament: Mg 34
Engine: 12-cylinder Maybach HL 120 TRM
Gun elevation: Manual
Gun rotation: Manual |
Released
Download |
|
SturmTiger_V2 |
German
SturmTiger
Main armament: 380
mm RW 61 rocket launcher
Secondary armament: Maschinengewehr 34
Engine:
Maybach HL 230 Engine, Electric Start
up
Gun elevation: Manual
Gun rotation: Manual |
Released
Download |
|
SturmTiger_V3 |
German
SturmTiger
Main armament: 380
mm RW 61 rocket launcher
Secondary armament: Maschinengewehr 34
Engine:Maybach HL 230 Engine,
Hand Crank
Start up
Gun elevation: Manual
Gun rotation: Manual |
Released
Download |
|
T-34 |
Russia
T-34
Main armament:
Secondary armament: 12.7mm Kord Heavy machine gun
Coaxial: 7.62mm PKMT
Engine:
V-2 Engine
Gun elevation: Manual
Gun rotation:
Motorized |
Released
Download |
|
T-34_2018 |
Russia
T-34
Main armament:
Secondary armament: 12.7mm Kord Heavy machine gun
Coaxial: 7.62mm PKMT
Engine:
V-2 Engine
Gun elevation: Manual
Gun rotation:
Motorized |
Released
Download |
|
T-55 |
Russia
T-55
Main armament:
Secondary armament:
Coaxial:
Engine:
Gun elevation: Manual
Gun rotation:
Motorized |
Released
Download |
|
T-90 |
Russia
T-90
Main armament: 2A46M 125 mm smoothbore gun
Secondary armament: 12.7mm Kord Heavy machine gun
Coaxial: 7.62mm PKMT
Engine: V-92S2 12-cyl. diesel
Gun elevation: Motorized
Gun rotation: Motorized |
Released
Download |
|
T1_V1 |
German
Tiger
I (Base on Tiger 131),
Main armament: 8.8 cm KwK
43 L/71
Secondary armament: Maschinengewehr 34
Engine:Maybach HL 230 Engine,
Hand Crank
Start up
Gun elevation: Manual
Gun rotation: Motorized |
Released
Download |
|
T1_V2 |
German
Tiger
I (Base on Tiger 131),
Main armament: 8.8 cm KwK
43 L/71
Secondary armament: Maschinengewehr 34
Engine:
Maybach HL 230 Engine, Electric Start
up
Gun elevation: Manual
Gun rotation: Motorized |
Released
Download |
*Please write to distributor or us for decompression password
Pre-built V1 sound packs for TK20/TK22/TK22A/TK35
|
Sound Set Code
|
Model
|
Release Schedule
/sound pack file |
|
T1 |
German tank version
German
Tiger
I (Base on Tiger 131),
Main armament: 8.8 cm KwK
43 L/71
Secondary armament: Maschinengewehr 34
Engine:
Maybach HL 230 Engine
Gun elevation: Manual
Gun rotation: Motorized |
Released |
|
ST |
German
SturmTiger
Main armament: 380
mm RW 61 rocket launcher
Secondary armament: Maschinengewehr 34
Engine:
Maybach HL 230 Engine
Gun elevation: Manual
Gun rotation: Manual |
Released |
|
T55
|
Russia
T-55 tank
Main armament:
Secondary armament:
Coaxial:
Commander's cupola
machine gun:
Engine:
Gun elevation: Manual
Gun rotation: Motorized |
Released |
|
T55A
(Hooben version) |
Russia
T-55A tank
Main armament:
Secondary armament:
Coaxial:
Commander's cupola
machine gun:
Engine:
Gun elevation: Manual
Gun rotation: Motorized |
Released |
|
RU/T34
|
Russia
Tank Version
( Based on T-34, V-2 Engine)
Main armament:
Secondary armament:
Coaxial:
Hull
Mount:
Engine:
V-2 Engine
Gun elevation: Manual
Gun rotation: Motorized |
Released |
|
US/M4
|
US tank Version
Main armament:
Secondary armament:
Hull
Mount:
Commander's cupola machine gun:
Engine:
Continental R975-C4 Engine
Gun elevation: Manual
Gun rotation: Motorized |
Released |
|
M41 |
US
M41 Walker Bulldog
Main armament:
Secondary armament:
Coaxial:
Commander's cupola
machine gun:
Engine: Continental
AOS 895-3 Engine
Gun elevation: Motorized
Gun rotation: Motorized |
Released |
|
KV
|
Russia
KV-1 and KV-2
 Main armament:
76.2 mm M1941 ZiS-5 gun
Secondary armament: DT MG
Engine: Model V-2 V12 Diesel engine
Gun elevation: Manual
Gun rotation:
Motorized |
Released |
|
PZ3 |
German
Panzer 3
Main armament:3.7 cm KwK 36
Secondary armament: Mg 34
Engine: 12-cylinder Maybach HL 120 TRM
Gun elevation: Manual
Turret rotation: Manual |
Released |
|
PZ4 |
German
Panzer 4
Main armament:7.5
cm KwK 40
Secondary armament: Mg 34
Engine: 12-cylinder Maybach HL 120 TRM
Gun elevation: Manual
Turret rotation: Manual |
Released |
|
Stug |
German
Stug
Main armament:7.5
cm KwK 40
Secondary armament: Mg 34
Engine: 12-cylinder Maybach HL 120 TRM
Gun elevation: Manual
Gun rotation: Manual |
Released |
|
PAN |
German
Panther
with Flammenvernichter Muffle
Main armament:7.5 cm KwK 40
Secondary armament: Mg 34
Engine: Maybach HL 230 P30 with Flammenvernichter Muffle
Gun elevation: Manual
Turret rotation: Motorized |
Released |
|
L2
|
German
Leopard 2, ZTZ-99 and TYPE10
Main armament:Rheinmetal GmbH
120mm
Secondary armament: MG3A1
Engine: MB873
Gun elevation: Motorized
Turret rotation: Motorized |
Released |
|
M26
|
US M26
and M4A3E8
Main armament: 90mm Tank Gun
Secondary armament: .30 Cal
Engine: Ford GAA V8 Tank Engine
Gun elevation: Manual
Turret rotation: Motorized |
Released |
|
JP |
German
JadgPanther
with Flammenvernichter Muffle
Main armament:8.8cm
Secondary armament: Mg 34
Engine: Maybach HL 230 P30 with Flammenvernichter Muffle
Gun elevation: Manual
Gun rotation: Manual |
Released |
|
M1
|
US
M1
Abrams
Main armament:120 mm L44 M256 smoothbore cannon
Secondary armament: M2HB heavy machine gun
Engine: Honeywell AGT1500C
Gun elevation: Motorized
Gun rotation: Motorized |
Released |
|
L1
|
German
Leopard 1
Main armament:105mm L7A3 L/52 rifled gun
Secondary armament: MG3
Engine: MTU MB 838
Gun elevation: Motorized
Gun rotation: Motorized |
Released |
|
GE
|
German
Gepard
Main armament:105mm L7A3 L/52 rifled gun
Secondary armament: 35 mm auto
cannon
Engine: MTU MB 838
Gun elevation: Motorized
Gun rotation: Motorized |
Released |
|
KT
|
German
King Tiger/Panther/JadgPanther
without Flammenvernichter
Muffle
Main armament: 8.8 cm KwK
43 L/71
Secondary armament: Maschinengewehr 34
Engine: Handcrank Maybach HL 230 P30
Hand Crank Start Up and
without Flammenvernichter
Muffle
Gun elevation: Manual
Gun rotation: Motorized |
Released |
|
38t |
Panzerkampfwagen 38(t)
Main armament: 3.7cm
Secondary armament: 7.92 mm ZB-53
Engine: Praga Typ TNHPS/II water-cooled, 6-cylinder
Gun elevation: Manual
Gun rotation: Manual |
Released |
|
JT |
German heavy tank destroyer
Jagdtiger
Main armament: 12.8 cm PaK 44
L/55
Secondary armament: Anti-aircraft MG-42
Engine: Handcrank Maybach HL 230 P30
Hand Crank Start Up and
without Flammenvernichter Muffle
Gun elevation: Manual
Gun rotation: Manual
*Speaker with better low frequency response is recommended for 12.8cm cannon
sound |
Released |
|
Hetzer |
German
Hetzer
Main armament:7.5 cm KwK 40
Secondary armament: Mg 34
Engine: Praga Typ TNHPS/II water-cooled, 6-cylinder
Gun elevation: Manual
Gun rotation: Manual |
Released |
|
CH2
|
UK Challenger 2
Main armament:L30A1 120 mm rifled gun
Secondary armament:
Coaxial: 7.62 mm L94A1 chain gun EX-34
Commander's cupola machine gun:
7.62 mm L37A2
Engine: Perkins CV-12 V12
Gun elevation: Motorized
Gun rotation: Motorized
Licensed from Reality Studio Sound Team
 |
Released |
|
M60
|
US
M60/48
Main armament:105mm L7A3 L/52 rifled gun
Secondary armament: M2HB heavy machine gun
Engine: Continental AVDS-1790-2 V12
Gun elevation: Motorized
Gun rotation: Motorized |
Sampling |
|
M2
|
US
Bradley IFV
Main armament:
25 mm M242 Chain Gun,
TOW Anti-Tank Missile
Secondary armament:7.62 mm M240C machine gun
Engine: Continental AVDS-1790-2 V12
Gun elevation: Motorized
Gun rotation: Motorized |
Sampling |
|
Hummel |
German
Sd Kfz 165 Hummel
Main armament:7.5
cm KwK 40
Secondary armament: Mg 34 Engine: 12-cylinder Maybach HL 120 TRM
Gun
elevation: Manual
Gun rotation: Manual |
Released |
|
JS |
Russia
JS-2/JS-3
Main armament:
122mm
Secondary armament: DShK Heavy Machine Gun
Engine: Model V-2 V12 Diesel engine
Gun
elevation: Manual
Gun rotation:
Motorized |
Released |
|
StuH 42 |
German
StuH 42
Main armament:
10.5 cm LeFH 18 L28
Secondary armament: Mg 34 Engine: 12-cylinder Maybach HL 120 TRM
Gun
elevation: Manual
Gun rotation: Manual |
Released |
|
Elefant |
German
Elefant Tank Destroyer
Main armament: 8.8 cm KwK
43 L/71
Secondary armament: Maschinengewehr 34 and 42
Engine: Twin Electric Motor, Twin Maybach HL 120 TRM
Gun elevation: Manual
Gun rotation: Motorized |
Released |
|
